Receiver: • Frequency Range: 470-932MHz (segmented) • Frequency Stability:± 10ppm • Sensitivity: 10dBuV • Adjacent Channel Rejection: 65dB • Image Frequency Rejection: 75dB • Audio Output: 200mV • Output Impedance: XLR connector: 200Ω; 1/4” connector: 1K • S/N Ratio: 100dB • Distortion: ＜0.1% • Frequency Response: 50Hz-18KHz • Receiving Distance: 100 (m) • Function Display: LCD • Power Supply: DC12V • Dimension: 210*180*45mm • Weight: approx. 745g • Material: iron case, aluminum panel  Transmitter: • Frequency Range: 470-932MHz (segmented) • Frequency Stability:± 10ppm • Transmit Power: 10mW • Receiving Distance: 100 (m) • Harmonic Suppression: >65dB • Modulation: FM • Max Modulation Degree: 75K • Operating Voltage: 3V • Operating Current: 120mA • Function Display: LCD

Product content
