Technical Data

EM 300-500 G4

• Frequency range

  AS: 520 - 558 MHz
  GBw: 606 - 678 MHz
  Gw: 558 - 626 MHz
  Bw: 626 - 698 MHz
  Cw: 718 - 790 MHz
  Dw: 790 - 865 MHz
  Aw+: 470 - 558 MHz
  Gw1: 558 - 608 MHz


• Dimensions

  Approx. 202 x 212 x 43 mm


• Compander

  Sennheiser HDX


• • THD, total harmonic distortion

    ≤ 0.9 %


  • Weight

    Approx. 980 g


  • Audio output

    6.3 mm jack socket (unbalanced): +12 dBu
    XLR socket (balanced): +18 dBu


  • Signal-to-noise ratio

    ≥ 115 dBA


  • Switching bandwidth

    up to 88 MHz


  • Peak deviation

    ±48 kHz


  • Nominal deviation

    ±24 kHz


  • Modulation

    Wideband FM


  • Power supply

    12 V DC


  • Antenna connector

    2 BNC sockets


  • Current consumption

    350 mA


  • Adjacent channel rejection

    Typically ≥ 75 dB


  • Intermodulation attenuation

    Typically ≥ 70 dB


  • Receiving frequency

    Max. 3520 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels


  • RF sensitivity

    < 2.5 μV for 52 dBA eff S/N


  • Squelch

    5 to 25 dBμV in steps of 2 dB


  • Equalizer

    Preset 1: Flat
    Preset 2: Low Cut (-3 dB at 180 Hz)
    Preset 3: Low Cut/High Boost (-3 dB at 180 Hz, +6 dB at 10 kHz)
    Preset 4: High Boost (+6 dB at 10 kHz)


  • Temperature Range

    -10 °C to +55 °C


  • Receiver Principle

    True diversity


  • Blocking

    ≥ 75 dB
